Designs include input, out, turbine, etc. Automatic applications Manual applications Transfer case applications Grobbed or flow formed housings
Capabilities include full design and development support In-house testing of designs Manufacture, assembly and end-of-line testing
| Product Specifications | |
|---|---|
| Voltage (V) | 800 |
| GAWR | 11,000 lbs. / 5,000 kg |
| Peak Output Torque (Nm) | 9,650 |
| Peak Power (kW) | 405 |
| Max Output Shaft Speed (RPM) | 913 |
| Park Lock | Optional (Electric Actuation) |
| Differential | Optional Limited Slip |
| Weight (kg) | 382 |
| Product Specifications | |
|---|---|
| Voltage (V) | 800 |
| GAWR | 17,500 lbs. / 7,938 kg |
| Peak Output Torque (Nm) | 15,300* |
| Peak Power (kW) | 350 |
| Max Output Shaft Speed (RPM) | 856* |
| Park Lock | Optional (Electric Actuation) |
| Differential | Optional Limited Slip |
| Weight (kg) | 580 |
| *Various with Ratio Selected | |
| Product Specifications | |
|---|---|
| Voltage (V) | 400 |
| GAWR | 11,000 lbs. / 5,000 kg |
| Peak Output Torque (Nm) | 4,090 |
| Peak Power (kW) | 150 |
| Max Output Shaft Speed (RPM) | 1,221 |
| Park Lock | N/A |
| Differential | Open |
| Product Specifications | |
|---|---|
| Voltage (V) | 400 |
| GAWR | 7,275 lbs. / 3,300 kg |
| Peak Output Torque (Nm) | 4,090 |
| Peak Power (kW) | 150 |
| Max Output Shaft Speed (RPM) | 1,221 |
| Park Lock | N/A |
| Differential | Open |
| Key Benefits |
|---|
